DEK Horizon 03iX SMT Stencil Printer

Printing cycle time:12 seconds
Maximum PCB: 510x508.5mm
Printing Pressure:0-20kg
Weight: Approx. 660 kg

DEK Horizon 03iX SMT Stencil Printer


DEK Horizon 03iX SMT Stencil Printer

DEK  is fully automatic SMT printer.
High-speed moving camera.
Advanced upper/lower vision system.

Technical Data:

Device alignment accuracy

> 2cpk@ +/ -12.5 microns, 6 sigma

Process alignment accuracy

> 2cpk@ +/ -25 microns, 6 sigma

Core printing cycle time

12 seconds (up to 11 seconds with HTC)

Scraper pressure mechanical system

Software control, motor drive

ISCANTM equipment control

Operation control using CAN BUS network


Color tablet touch screen, keyboard and trackball, DEK InstinctivTM V9 user interface

Screen orientation

Manually load using the mesh frame depth regulator

Maximum substrate handling size

510 mm (X) X 508.5 mm (Y)

Minimum substrate handling size

50 mm (X) X 40.5 mm (Y)

The thickness of the substrate

From 0.2 mm to 6 mm

Base board weight

1 kg

Rail type

Use a 3 mm round belt integral transmission system

The visual system


Camera lighting

Software controlled programmable LED lighting
