SMT Selective Coating Machine SC460

SMT Selective Coating Machine SC460

Specifications:

SMT Selective Coating Machine SC460

The X-Y-Z-U four-axis movement and whole-piece welding of reinforced rack ensure stable high-speed operation;

The selective coating allows precise coating of selected zones;

No uncoated area, with U axis capable of rotating 180 degrees in two directions, rubber valve turning 35 degrees to completely coat the whole workpiece;

The X, Y and Z all have imported linear module and are driven by imported servo motor which provides high speed, stability and precise positioning and achieves high speed and precise coating;

The Z axis is in combination with professional and precise coating valve to ensure uniform coating;

ning and achieves high speed and precise coating;

Equipped with online programming system to support coating paths including point, line, circle and zone, and allow coating on various PCBs;

Appliable to PCBA surface coating, dam process, solder mask coating, and DIP components reinforcement;

Name	460F
Appearance of Size	900*1260*1550 (L*W*H)	900*1260*1550 (L*W*H)
Board Size	450*450(MAX),50*50(MIN)	450*450(MAX),50*50(MIN)
Height of Maximum Component	Top and bottom 100mm each	Fop and bottom 100mm each
Height	900±20mm	900±20mm
Transmission Power	86 stepper motor	86 stepper motor
Transmission Method	25 # stainless steel chain	25 # stainless steel chain
Adjustable Method	Electric Adjustable	Electric Adjustable
Whether to Reserve the Backplane	Yes	Yes
Whether with U Axis	Without U Axis	With U Axis
Valve Available	Two	Three
Maximum Speed	1000mm/s	1000mm/s
Position Accuracy	±0.02mm	±0.02mm
Repeat Accuracy	±0.02mm	±0.02mm
Axis	3 sets	4 sets
Valve Type	Fine Atomization Valve, Needle Dispensing Valve (Membrane Valve optional)	Fine Atomization Valve, Needle Dispensing Valve (Membrane Valve optional)
Voltage	220V 50-60HZ	220V 50-60HZ
Input air Pressure	0.3-0.6Kpa	0.3-0.6Kpa
Total Power	1.8KW	2KW
